TRAIS UR-600 Cost-effective 2 Channels True Diversity Wireless Microphone for Events (Optional: Handheld/Bodypack/Headset/Lavalier Mic)

● Professional small performance wireless system, suitable for small performances, school projects. ● Microcomputer dual CPU control: the entire hardware circuit is controlled by microcomputer, which can be processed such as frequency selection, display, battery capacity monitoring, etc., to achieve various functions that are not easy to achieve by traditional models. ● In complex outdoor environments and bad weather, signal reception is stronger and more stable, and receiving range can reach 200 meters. ● Receiver adopts digital LCD interface display, system working status is clear. ● DPLL multi-channel frequency synthesis technology and automatic noise control technology. ● True diversity wireless system, high-gain antenna, eliminate dead Angle constant communication, improve receiving stability. ● With one-click intelligent switching bodypack/handheld function. ● High frequency circuit design with double frequency conversion, with high sensitivity and high fidelity tone, interference noise squelch function. ● It has function of suppression and attenuation of whistling in return, which can effectively reduce whistling in return.

Categories:

Professional Wireless Microphone

Download:

Keywords:

Inquire Now

Product details

UR-600 Professional True Diversity Performance Wireless Microphone

Product Features:
● Professional small performance wireless system, suitable for small performances, school projects.
● Microcomputer dual CPU control: the entire hardware circuit is controlled by microcomputer, which can be processed such as frequency selection, display, battery capacity monitoring, etc., to achieve various functions that are not easy to achieve by traditional models.
● In complex outdoor environments and bad weather, signal reception is stronger and more stable, and receiving range can reach 200 meters.
● Receiver adopts digital LCD interface display, system working status is clear.
● DPLL multi-channel frequency synthesis technology and automatic noise control technology.
● True diversity wireless system, high-gain antenna, eliminate dead Angle constant communication, improve receiving stability.
● With one-click intelligent switching bodypack/handheld function.
● High frequency circuit design with double frequency conversion, with high sensitivity and high fidelity tone, interference noise squelch function.
● It has function of suppression and attenuation of whistling in return, which can effectively reduce whistling in return.

Receiver Technical Parameter
Frequency Range: UHF613-637.75MHz, 645-669.75MHz
Frequency Quantity: 200 frequency points adjustable
Effective working distance: Generally 200 meters (open space)
Modulation mode: FM
Mode of oscillation: PLL frequency synthesizer
Frequency stability: ±0.0005%
Sensitivity: The offset is equal to 25KHz
If you input 6dBμV, S/N is greater than 60dB
Maximum offset: ±45kHz
Band width: 50MHz
Comprehensive SNR: >108 dB
Comprehensive T.H.D. : < 0.4%@1 KHz
Comprehensive frequency response: 60Hz~18kHz ± 3dB
Maximum output voltage: Balance type: -20dBV/100Ω
Unbalanced type: -4dBV/5KΩ
Output socket: XLR balanced type and 6.3φ unbalanced type socket
Power supply: 100-240V，AC50/60Hz, 10W

Transmitter Parameters
Oscillation mode: PLL frequency synthesizer
Harmonic radiation: < -63dBm
Band width: 80MHz
Maximum offset: ± 45KHz
Power output: 30mW
Frequency response: 50Hz~18KHz
Max input sound pressure: 130dB SPL
Sound head: Imported dynamic mic core
RF power output: 8mW; 8mW/15mW (Selectable)
Current consumption: <110 mA
Battery Specification: 2 x 1.5V AA Battery
